How to predict the performance of cylinders? Predictive maintenance based on vibration signals

As the core actuator of industrial automation systems, the reliability of cylinders directly affects production efficiency. According to statistics, 35% of pneumatic system failures are caused by cylinder wear, and sudden failures can cause production lines to lose up to tens of thousands of yuan per hour. Traditional regular maintenance has the risk of over-maintenance or missed inspections, while predictive maintenance based on vibration signals can accurately capture early signs of wear and achieve early intervention of faults.

1. Generation mechanism of cylinder vibration signals

Typical vibration sources

Piston seal wear: Damage to the seal ring causes compressed air leakage, causing unstable piston movement (frequency: 10-100Hz)

Guide sleeve clearance: Exceeding the matching tolerance causes the piston rod to swing (characteristic frequency: 50-300Hz)

Buffer valve failure: Poor exhaust produces high-frequency pressure fluctuations (frequency band: 500-2000Hz)

Vibration signal characteristic parameters

2. Three core methods of vibration diagnosis

Method 1: Time domain feature analysis method

Applicable scenario: Rapid screening of early abnormalities

Key indicators:

RMS value (root mean square): 20% above the baseline value is an early warning

Peak factor (CF): >3.5 indicates impact wear

Operation steps:

Install a three-axis acceleration sensor at the midpoint of the cylinder stroke

Collect vibration data for 10 working cycles

Calculate the Z-score of CF and RMS (alarm if it deviates from the baseline by 3σ)

Method 2: Frequency domain envelope demodulation technology

Applicable scenario: Accurately locate faulty components

Technical principle: Extract the modulation signal through Hilbert transform and separate the bearing/seal characteristic frequency

Diagnostic process:

The sampling frequency is set to 5kHz

Envelope spectrum analysis is performed on the 200-800Hz frequency band

Identify characteristic frequencies:

Piston rod speed × number of balls (bearing failure)

Sealing friction pair passing frequency (seal wear)

Measured data: A packaging machinery cylinder has a sideband at 125Hz, which is diagnosed as guide sleeve wear (vibration is reduced by 62% after repair).

Method 3: Machine learning intelligent diagnosis

Applicable scenario: multi-cylinder cluster monitoring

Model architecture:

Input layer: 1s vibration segment (including time domain + frequency domain features)

Hidden layer: 3-layer LSTM network (128 memory units)

Output layer: fault type classification (accuracy > 92%)

Implementation path:

Collect historical data (500 groups of normal/wear status each)

Data enhancement (add Gaussian noise to improve generalization)

Deploy edge computing module

3. Diagnostic System Construction Guide

Hardware Selection Recommendations
